Landcruiser 76, 78 & 79 Series GVM Upgrade

The DMW GVM upgrade for the Landcruiser 70 Series will increase your vehicle's legal carrying load up to an impressive 4499kg, without affecting handling or performance. We offer fully compliant and QA-checked upgrade options with federally approved SSM (Second Stage Manufacturer) certification, available for both pre and post registration vehicles.

Price includes professional installation. The listed price is fully fitted -- DMW components supplied and installed at our workshop, plus wheel alignment and all engineering compliance work. Select your configuration and registration status (Pre Rego or Post Rego) to see the final price. No additional fitting fee at checkout.

GVM Upgrade Options for the Landcruiser 70 Series

Option 1: 3999kg GVM

79SC, 79DC, 76 & 78 Series

• Engineered and federally approved GVM upgrade including SSM certification
• Engineering support available for post-registration engineering compliance with approved signatories
• GVM upgrade includes the fitting of compliant components including upgraded shock absorbers with a choice of the no-nonsense DMW IMS shock or the full adjustability of the remote reservoir MRA shock
• Paired with upgraded springs to handle the extra weight and an array of other components to improve both ride and handling
• Package features lifts of between 40-75mm and wheel and tyre combinations up to 35" depending on vehicle's load and distribution
• Some State and Territory restrictions apply to post-registration lift height, wheel size and offset

Option 2: 4499kg GVM

79SC, 79DC, 76 & 78 Series

• Engineered and federally approved GVM upgrade including SSM certification
• Engineering support available for post-registration engineering compliance with approved signatories
• Become "King of the Load" with DMW's 4499kg GVM upgrade
• Featuring a replacement rear diff housing with chrome moly axles, increased rear axle load to 2900kg and track correction
• Engineered and FEA-derived chassis bracing added to give strength where needed and protect from chassis failure at high stress points
• Solves the 70 Series lack-lustre braking with a full hydraulic brake booster, braided stainless brake lines and a handbrake upgrade
• Upgraded shock absorbers with choice of DMW IMS or remote reservoir MRA
• Load rated wheels and tyres required to meet upgraded axle loads -- DMW have a number of great combinations available
• Package features lifts of between 40-75mm and wheel and tyre combinations up to 35"
• Some State and Territory restrictions apply to post-registration lift height, wheel size and offset

DMW Suspension Package

The GVM upgrade includes the fitting of compliant components including upgraded shock absorbers, with a choice between two DMW shock options:

• XT IMS -- the no-nonsense DMW IMS monotube shock. Built for extreme durability, load carrying and reliable comfort with exceptional handling.
• XT MRA -- full adjustability with the remote reservoir adjustable shock, tuned to handle the toughest roads. Features 11-stage rebound, 16-stage low-speed and 14-stage high-speed compression adjustment for total ride control.

Both options are paired with upgraded springs to handle the extra weight, plus an array of supporting components to improve ride quality and handling.

Finite Element Analysis (FEA) & Brake Testing

To hold federal approvals as a Second Stage Manufacturer, DMW completes exhaustive FEA testing and analysis plus brake testing to ensure your vehicle is safe at the increased GVM. FEA is a computer simulation technique that analyses GVM upgrade products in detail for stress, vibration, heat transfer and many other physical characteristics. Combined with brake testing, this ensures your family is safe and your vehicle is insured once the GVM upgrade has been added.

GCM Upgrades by State

GVM upgrades are approved across all Australian states and territories, both pre and post registration. GCM (Gross Combination Mass) upgrades vary by jurisdiction -- key notes:

• QLD, WA, ACT & NT: GCM upgrade NOT approved on in-service (registered) vehicles; approved pre-registration under SSM.
• NSW, SA, VIC & TAS: GCM upgrade approved both pre and post registration (subject to compliance signatory).
• BTC (Braked Towing Capacity) upgrades are not permitted on light vehicles under any state.

A vehicle that is legally registered in one Australian state or Territory with a BTC, GVM or GCM upgrade can legally travel in another state or Territory. Actual GVM increase and availability subject to specific model variants.
