• Silverado 2500 HD 6,000kg GVM Upgrade, 3" Lift, OK 2.5" Shocks, Airbags, 815kg SuperSprings

Outback Kitters BDS

Silverado 2500 HD 6,000kg GVM Upgrade, 3" Lift, OK 2.5" Shocks, Airbags, 815kg SuperSprings (Installed)

AG802003-60K2-51 (Kit)

$15,150.00
$15,150.00
Tax included.
Supplied & Fitted Price
Supplied & Fitted Price

Outback Kitters 2.5" Remote Reservoir Compression Adjustor Shocks including BDS Upper Control Arms, Boss Airbags Triple Bellow +1,136kg Rated Load Assist Kit and Rear 815kg SuperSprings.

Specifications

GVM 6,000kg
BTC 4,500kg
Payload 2,198kg
GCM 12,474kg
Front Axle 2,700kg
Rear Axle 3,330kg
Requires Wheel/Tyre Upgrade Yes
Wheel Load Rating 1644KG
Tyre Load Rated 125Q
Maximum Tyre Size 35x12.5xR18, 35x12.5xR20, 37x12.5xR18, 37x12.5R20
Wheel Offsets 0 +12 +18
Front Lift Height 3"
Front Lift Method Torsion Key
Rear Lift Height 2"
Rear Lift Method Leaf Helper
Rear Lift Option 815kg Load Rated
Licence NB2 (light rigid) required

Fitment & compliance notes

  • Suits Chevrolet Silverado 2500 HD 2020–2026 models.
  • Pre-registration compliance available in all states. Post-registration compliance: QLD, NSW, ACT, VIC, TAS, SA.
  • GVM Upgrade Requires Wheel/Tyre Upgrade.
  • Stock wheels and stock tyres cannot be reinstalled due to tie rod end interference.
  • Disassembly/assembly of the factory torsion bar system requires the use of a special unloading tool (See OK221001).
  • Some minor trimming may be necessary to fit certain wheel/tire combination. This is normal with most aftermarket tire/wheel fitment on Chevy/GM trucks and typically consists of trimming the bottom edge of the inner fender shrouds and/or lower corner of front bumper valance. As a rule of thumb, deeper backspacing and shorter/ narrower tires will reduce/eliminate trimming required.
  • Will NOT work with AT4X or ZR2 models, lower control arm profile is different.
  • Price is supplied and fitted, and includes installation, a wheel alignment and consumables. Wheels and tyres, flares and painting are additional.
Silverado 2500 HD 6,000kg GVM Upgrade, 3" Lift, OK 2.5" Shocks, Airbags, 815kg SuperSprings (Installed)

$15,150.00
