Silverado 2500 HD 6,000kg GVM Upgrade, 5" Lift, OK 2.5" Shocks, Airbags, 815kg SuperSprings (Installed)

This kit includes Outback Kitters 2.5" Shocks including BDS Upper Control Arms, Boss Airbags Double Bellow +1,136kg Rated Load Assist Kit and Rear SuperSprings +815kg Helper Kit.

Specifications

Fitment & compliance notes

• Suits Chevrolet Silverado 2500 HD 2020–2026 models.
• Pre-registration compliance available in all states. Post-registration compliance: QLD, NSW, ACT, VIC, TAS, SA.
• For DRW models, use the w/ overload rear lift option.
• Requires frame bracket modification.
• Torsion Bar Tool required to load/unload torsion bars.
• Models with two-piece rear driveshafts will require a carrier bearing drop kit.
• In some cases, vehicles used in 4WD on the highway frequently could potentially experience a minor front driveline vibration. If this occurs we recommend replacing the front driveshaft with a dual Cardan style driveshaft.
• Do not install this suspension system in conjunction with any type of torsion bar lift keys to achieve more than the tested 5" lift height.
• Some minor trim will be required with certain wheel/tire combinations. This is normal with most aftermarket tire/wheel fitment on Chevy/GM trucks. Trimming will normally include the bottom edge of the inner fender shrouds and/or the lower corner of the front bumper valance. As a rule of thumb, deeper backspacing and shorter/narrower tires will reduce/eliminate trimming required.
• Will NOT work with AT4X or ZR2 models, lower control arm profile is different.
• Price is supplied and fitted, and includes installation, a wheel alignment and consumables. Wheels and tyres, flares and painting are additional.
