Silverado 2500 HD 6,000kg GVM Upgrade, 5" Lift with OK 2.5" Shocks, Airbags, Leaf Pack (Installed)

This kit includes Front & Rear Outback Kitters 2.5" Remote Reservoir DSC Shocks, including BDS Upper Control Arms, Boss Airbags Double Bellow +1,136kg Rated Load Assist Kit and a 400kg Constant Load Rated Leaf Pack with 2" Blocks.

Specifications

Fitment & compliance notes

• Suits Chevrolet Silverado 2500 HD 2020–2026 models.
• Pre-registration compliance available in all states. Post-registration compliance: QLD, NSW, ACT, VIC, TAS, SA.
• For DRW models, use the w/ overload rear lift option.
• Requires frame bracket modification.
• Torsion Bar Tool required to load/unload torsion bars.
• Models with two-piece rear driveshafts will require a carrier bearing drop kit.
• In some cases, vehicles used in 4WD on the highway frequently could potentially experience a minor front driveline vibration. If this occurs we recommend replacing the front driveshaft with a dual Cardan style driveshaft.
• Do not install this suspension system in conjunction with any type of torsion bar lift keys to achieve more than the tested 5" lift height.
• Some minor trim will be required with certain wheel/tire combinations. This is normal with most aftermarket tire/wheel fitment on Chevy/GM trucks. Trimming will normally include the bottom edge of the inner fender shrouds and/or the lower corner of the front bumper valance. As a rule of thumb, deeper backspacing and shorter/narrower tires will reduce/eliminate trimming required.
• Will NOT work with AT4X or ZR2 models, lower control arm profile is different.
• Price is supplied and fitted, and includes installation, a wheel alignment and consumables. Wheels and tyres, flares and painting are additional.
